8GB RAM
KINGSTON DDR5 KVR56U46BS6-8
8GB RAM
KINGSTON DDR5 KVR56U46BS6-8
| Specifications for KVR56U46BS6-8 | |
|---|---|
| Features | |
| Buffered memory type | Unregistered (unbuffered) |
| CAS latency | 46 |
| Component for | PC/Server |
| ECC | No |
| Internal memory | 8 GB |
| Internal memory type | DDR5 |
| JEDEC standard | Yes |
| Lead plating | Gold |
| Memory clock speed | 5600 MHz |
| Memory form factor | 288-pin DIMM |
| Memory layout (modules x size) | 1 x 8 GB |
| Memory ranking | 1 |
| Memory voltage | 1.1 V |
| Module configuration | 1024M x 64 |
| On-Die ECC | Yes |
| Programming power voltage (VPP) | 1.8 V |
| Refresh row cycle time | 295 Nanosecond |
| Row active time | 32 Nanosecond |
| Row cycle time | 48 Nanosecond |
| SPD profile | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 85 °C |
| Storage temperature (T-T) | -55 - 100 °C |
| Package dimensions | |
| Gross Weight (Package, kg) | 0.13 kg |
| Product dimensions | |
| Net Weight (Product, kg) | 0.1 kg |
| Product Height | 3.13 cm |
| Product Width | 13.33 cm |
| Sustainability | |
| Doesn't contain | Halogen |
| Sustainability certificates | RoHS |
| Sustainability compliance | Yes |
| Technical details | |
| Compliance certificates | RoHS |
